Description
| Specification | Details |
|---|---|
| Brand | ASUS |
| Model | PRIME B760M‑R D4 (90MB1HA0‑M0EAY0) |
| Form Factor | micro‑ATX (24.4 × 21.1 cm) |
| CPU Socket | Intel LGA 1700 (supports 12th- 13th & 14th Gen Intel Core; Pentium/Celeron) |
| Chipset | Intel B760 |
| Memory Support | 2 × DDR4 DIMM slots- up to 64 GB- up to 5333 MHz via XMP |
| Expansion Slots | 1 × PCIe 4.0 x16- 1 × PCIe 3.0 x16 (x4 mode)- 2 × PCIe 3.0 x1 |
| M.2 Slots | 2 × PCIe 4.0 x4 M.2 (2242/2260/2280) |
| SATA Ports | 4 × SATA 6 Gb/s |
| USB Ports (Rear) | 4 × USB 5 Gbps Type‑A- 4 × USB 2.0 Type‑A |
| USB Headers (Internal) | 1 × USB 5 Gbps header- 2 × USB 2.0 headers (total support up to 6 front ports) |
| Video Output | HDMI (up to 4K @ 60 Hz) |
| Ethernet | Realtek RTL8125B- 2.5 GbE |
| Audio | Realtek ALC897 codec- 7.1‑channel HD audio |
| RGB Headers | 3 × Addressable Gen 2 headers (Aura Sync) |
| Cooling Interface | VRM heatsink- PCH heatsink- hybrid fan headers |
| Special Features | AI Two-Way Noise Cancellation- ASUS 5X Protection III- Fan Xpert 2+ |
| BIOS | UEFI BIOS with Intelligent Control |
| Weight / Dimensions | Approx. 0.8 kg / 24.4 × 21.1 cm |
| Included Accessories |
I/O shield- 2 × SATA cables- M.2 standoffs- quick start guide |
ASUS Prime B760M‑R D4 Motherboard (Micro‑ATX- LGA 1700- DDR4)
Features and Detailed Information
Compatibility with Latest Intel CPUs
This motherboard supports Intel LGA 1700 socket and is compatible with Intel Core 12th- 13th- and 14th Gen processors- as well as Pentium Gold and Celeron models. It supports Intel Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0- depending on CPU model.
High-Speed Connectivity
PCI Express 4.0 support includes one full‑length PCIe 4.0 x16 slot (for graphics cards) and two PCIe 4.0 M.2 slots with x4 lanes for fast NVMe SSD storage. Realtek 2.5 Gb Ethernet on board provides faster networking than standard gigabit connections.
Memory Support
Two DDR4 DIMM slots support up to 64 GB of memory. Supported speeds include overclocked profiles up to DDR4‑5333 MHz via XMP- while standard speeds cover DDR4‑2133 to DDR4‑3200.
Cooling and Fan Control
Equipped with VRM and PCH heatsinks- multiple hybrid fan headers- and the ASUS Fan Xpert 2+ system- this board delivers efficient thermal management under heavy loads.
Customization and Lighting
Includes addressable Gen 2 RGB headers for LED strips compatible with Aura Sync- allowing synchronized lighting across compatible hardware.
AI Noise Cancellation
Built-in two-way AI noise cancellation reduces unwanted background noise from microphone input and audio output- enhancing communication clarity for gaming and video conferencing.
Audio Features
Employs Realtek ALC897 audio codec with 7.1-channel high-definition audio support. Features include audio shielding- dedicated left/right PCB layers- and premium audio capacitors for better fidelity.
Extensive I/O and Expansion
Rear I/O includes: HDMI port (supports up to 4K 60 Hz)- 4 × USB 5 Gbps Type-A- 4 × USB 2.0 Type-A- Realtek 2.5 Gb LAN- and 3 audio jacks.
Internal headers provide additional front‑panel support for 2 × USB 5 Gbps- 4 × USB 2.0- 3 addressable RGB headers- Clear-CMOS button- TPM header- speaker- S/PDIF out- and more.
Questions and Answers
Q: Why choose this motherboard over other budget models?
A: It combines modern features such as PCIe 4.0- dual M.2 slots- DDR4 XMP support up to 5333 MHz- 2.5 GbE networking- RGB headers- and AI noise cancellation—all in a compact micro‑ATX board.
Q: Can it handle high-speed RAM and SSDs smoothly?
A: Yes. Dual-channel DDR4 memory up to 5333 MHz via XMP and two PCIe 4.0 M.2 slots allow for fast memory and storage performance.
Q: Is the cooling adequate for demanding workloads or AI tasks?
A: Yes. The board features VRM and chipset heatsinks with fan headers and customizable control via Fan Xpert 2+- ensuring temperature management under load.
Q: Are there any reliability concerns reported by users?
A: Some users in online forums noted issues with BIOS compatibility affecting XMP memory registers- but recent BIOS updates (W32 and W40 series) have addressed many of those concerns. Asus boards require occasional BIOS updates to maintain optimal memory behavior.
Q: Does it integrate well in compact systems?
A: Yes. Its micro‑ATX form factor (24.4 × 21.1 cm) makes it suitable for compact builds without sacrificing core functionality
